1 783,79 € (13 439,97 kn)
| Specifications | |
|
|
|
| Frequency response | 68 – 19.000Hz ±3dB |
| LOW CUT Mode 2 | 100 – 19.000Hz ±3dB |
| LOW CUT Mode 3 | 120 – 19.000Hz ±3dB |
|
|
|
| Max. SPL (1m, free field) | 129dB |
|
|
|
| Nominal horizontal dispersion | 100° |
|
|
|
| Nominal vertical dispersion | 60° |
|
|
|
| Transducers | LF: One 8″ ND cone |
| HF: One 1.5″ Ring diaphragm compression driver | |
|
|
|
| Power handling AES RMS/peak | LF: 200W / 400W |
| HF: 50W / 100W | |
|
|
|
| Amplifier | Integrated, 2 powerstages: 1x PWM 1x Linear Power Stage |
| Power Supply | SMPS (Switched Mode Power Supply) with power factor correction (PFC) |
| DSP | 32-bit, floating point, 192 kHz Sampling frequency |
| Filter Technology | IIR and FIR filters, delay adjustments, contour filters |
|
|
|
| Power input | powerCON 110-240V 50-60Hz |
| Signal input | XLR3-F and XLR3-M |
|
|
|
| Dimensions (H x W x D) | 400 x 240 x 280 mm |
| 15.7 x 9.4 x 11.0” | |
|
|
|
| Weight | 10.5 kg |
| 23.1 lb |
